CBL plans, manufactures and installs optical and microwave radio-link systems for wireless site-to-site interconnection from 100 MBit/s to 10 GBit/s.
CBL - Communication by light - Gesellschaft für optische Kommunikationssysteme mbH
Darmstädter Str. 81 · 64839 Münster (Hessen)New on Amplifa
About CBL
CBL GmbH (Communication by light), based in Münster (Hesse) near Dieburg, has specialized in radio-link technology for wireless site-to-site interconnection since 1991. The company develops and manufactures optical laser systems (AirLaser series), short-range and microwave radio-link systems (CBL-Link, AirLink) as well as passive deflection mirrors in lightweight aluminum construction, and offers accessories such as hot-dip galvanized brackets and masts. More than 30 years of experience have gone into over 2,500 radio-link systems installed in Germany and thousands of deliveries to more than 16 countries. The service portfolio covers the entire value chain from a single source: feasibility studies, radio-path and site planning, frequency application formalities with the Federal Network Agency (Bundesnetzagentur), infrastructure creation including steel construction and cable laying, installation, commissioning as well as maintenance and service. In addition, CBL develops and produces OEM products, in particular active components for in-house cabling systems such as the ISABEL mini-switch series, with expertise in optical communications technology, IP signal processing and digital signal processing. Customers come from industries such as mobile communications, chemicals, mechanical engineering, banks, clinics and public institutions.
