PCB assembly (SMD/THT) for prototypes, express orders from 72 hours and small to medium series in Berlin.
Dietz Leiterplattenbestückung GmbH & Co. KG
BerlinNew on Amplifa
About Dietz Leiterplattenbestückung
Dietz Leiterplattenbestückung GmbH & Co. KG is a certified EMS provider in Berlin, specializing in the assembly of printed circuit boards for prototypes, samples, small batches and small to medium series. The service portfolio includes SMD assembly, mixed SMD/THT assembly (also double-sided), express PCB assembly from 72 hours, material procurement including material purchasing and interim storage, cable assembly, device and module assembly, and functional testing according to customer specifications. Production combines fully automatic placement systems of the EXPERT line (Essemtec) with a capacity of up to 7000 components per hour and precise manual work; components down to the 01005 package size are processed. Quality assurance is carried out according to IPC-A-610 (Class 2 and 3) with manual visual inspection, microscope checks and 3D AOI. Customers come, among others, from the automotive industry, the medical sector, mechanical and plant engineering, industrial electronics, telecommunications, energy technology, laboratory technology, facility management and agricultural and forestry machinery. The company was founded in 2008 and manufactures at its Berlin site.
- Site
- Berlin
- Processes
- SMD assembly (SMT), THT assembly, SMD/THT mixed assembly (also double-sided), Prototype assembly (prototypes, samples, small batches), Series assembly (small to medium series, standard delivery time 10 working days after material, Cable assembly, Functional test (according to customer provision/specifications), Device and module assembly
- Materials
- Passive standard components (stocked), SMD components down to 01005 package size, THT components, Printed circuit boards
- Certificates
- ISO 9001:2015, ISO 9001, IPC-A-610 (Class 2 & 3), EN 9100 (targeted)
- Founded
- 2008
- Employees
- fewer than 10
- Industries
- Automotive industry, Laboratory technology, Facility management, Medical sector, Mechanical and plant engineering, Industrial electronics
- 01
- 02
Data verification and quotation preparation
- 03
SMD/THT assembly (also express from 72 hours)
- 04
Soldering (automatic soldering system)
- 05
Quality assurance (visual inspection, 3D AOI, IPC-A-610)
- 06
Functional test according to customer specifications
- 07
Device and module assembly, cable assembly
Processes & Components
SMD components down to 01005 package size
Processing of the finest components down to the 01005 package size on fully automatic placement systems.
THT components
Through-hole technology for mixed assembly and robust modules.
Passive standard components (stocked)
Extensive stocking of passive standard components guarantees flexibility and shorter delivery times.
Printed circuit boards
Procurement and assembly of printed circuit boards, also completely via material purchasing.
Site
Berlin
DEProduction / Administration
- Materials
- Printed circuit boards, SMD and THT components down to 01005 package size, cables
- Fully automatic SMD placement system Essemtec EXPERT line (up to 7000 components/h)
- Automatic soldering system
- 3D AOI (automatic optical inspection)
- Quins easy alternating-image inspection system
Modules & Services
Inside the production
Industries
Processes & technical limits
| Processes | Tolerance | Max. part | Weight | Lot size | Materials |
|---|---|---|---|---|---|
| SMD assembly (SMT)Assembly | – | – | – | – | Printed circuit boards, electronic components down to 01005 |
| THT assemblyAssembly | – | – | – | – | Printed circuit boards, THT components |
| SMD/THT mixed assembly (also double-sided)Assembly | – | – | – | – | Printed circuit boards |
| Assembly | – | – | – | 1 piece – 10 printed circuit boards per order | Printed circuit boards |
| Prototype assembly (prototypes, samples, small batches)Assembly | – | – | – | – | Printed circuit boards |
| Series assembly (small to medium series, standard delivery time 10 working days after materialAssembly | – | – | – | – | Printed circuit boards |
| Engineering | – | – | – | – | Electronic components, printed circuit boards |
| Cable assemblyAssembly | – | – | – | – | Cables |
| Functional test (according to customer provision/specifications)Testing | – | – | – | – | Modules |
| Device and module assemblyAssembly | – | – | – | – | Modules, devices |
| Testing | – | – | – | – | Printed circuit boards, modules |
4 Anlagen & Maschinen
| Machine | Manufacturer / model | Quantity | Working area | Year built | Site |
|---|---|---|---|---|---|
| Fully automatic SMD placement system (up to 7000 components per hour) | Essemtec EXPERT line | – | – | – | Berlin, Germany |
| Automatic soldering system | – | – | – | – | Berlin, Germany |
| 3D AOI (automatic optical inspection) | – | – | – | – | Berlin, Germany |
| Alternating-image inspection system (manual visual inspection) | Quins easy | – | – | – | Berlin, Germany |
Additional services
Quality & Certification
All printed circuit boards are 100 % inspected: by manual visual inspection (Quins easy alternating-image method), microscope checks and, by arrangement, 3D AOI. Testing and evaluation are carried out according to IPC-A-610 (Class 2 and 3), with complete logging, documentation and archiving on request.
| Evidence | Berlin |
|---|---|
| ISO 9001 | |
| IPC-A-610 (Class 2 & 3) | |
| EN 9100 (targeted) |
History
- 2008
Start of PCB assembly; specialization in prototypes and small to medium series.
- 2024
ISO 9001:2015 certificate issued by DEKRA (valid until 25.03.2027); preparations for DIN EN 9100 and TISAX are underway.
