Manufacture of high-quality fibre-composite and carbon components from prototype to series production, including toolmaking and painting
HMB Holzner Maschinenbau GmbH
Heroldstatt (72535)New on Amplifa
About HMB Holzner Maschinenbau
HMB Holzner Maschinenbau GmbH, based in Heroldstatt, manufactures high-quality composite components made of fibre-reinforced materials such as carbon. The service spectrum covers the complete value chain from cutting of the raw materials through manufacturing to assembly of the assemblies. In its own toolmaking department, complex tools and jigs are produced with two modern 5-axis milling machines and state-of-the-art CAM technology. The company serves prototype and single-part production, small series and series production, in which CNC-controlled finishing centres complement the shop-floor production. In addition, painting work is carried out according to customer specifications, including primer, topcoat and carbon finish. Customers come in particular from the aerospace industry; all components undergo a 100% inspection before delivery.
- Site
- Heroldstatt
- Processes
- Prototypes and single parts (state-of-the-art machine fleet, fast production), Small series (shop-floor production, manual mechanical finishing at low volumes), Series production (CNC-controlled finishing centres complement shop-floor production for large, Toolmaking (complex tools and jigs, latest CAM technologies), Manufacturing from cutting of the raw materials through to assembly (composite components), Painting (primer, topcoat, final inspection, carbon finish), Quality assurance with 100% inspection of all components, Optical 3D measuring system / 3D scanner (contactless geometry inspection, CAD comparison)
- Materials
- Fibre-composite components, Carbon (carbon finish, composite components), Carbon (fibre composite), Fibre-reinforced materials
- Certificates
- ISO 9001:2015, EN 9100:2018
- Industries
- Aerospace, Fibre-composite/composite components
- 01
Toolmaking (5-axis milling)
- 02
Cutting of the raw materials
- 03
Manufacture of the composite components
- 04
CNC finishing
- 05
Painting (primer, topcoat, carbon finish)
- 06
Assembly
- 07
Final inspection / outgoing goods inspection
Materials & Processes
Carbon (fibre composite)
Material for high-quality composite components with carbon finish for applications including aerospace.
Fibre-reinforced materials
Base material of the manufactured components and assemblies from cutting through to assembly.
Locations
Heroldstatt
DEHeadquarters and manufacturing
- Lot size
- Single parts to series
- Materials
- Fibre-reinforced materials, carbon
- 2x 5-axis milling machine
- CNC-controlled finishing centre
- Optical 3D measuring system
- Ultrasonic testing system
Industries
Processes & technical limits
| Processes | Tolerance | Max. part | Weight | Lot size | Materials |
|---|---|---|---|---|---|
| Prototypes and single parts (state-of-the-art machine fleet, fast production)Engineering | – | – | – | 1 – Single parts | – |
| Small series (shop-floor production, manual mechanical finishing at low volumes)Joining | – | – | – | – | – |
| Series production (CNC-controlled finishing centres complement shop-floor production for largeMachining | – | – | – | – | – |
| Toolmaking (complex tools and jigs, latest CAM technologies)Engineering | – | – | – | – | – |
| Manufacturing from cutting of the raw materials through to assembly (composite components)Assembly | – | – | – | – | Fibre-composite components, Carbon |
| Painting (primer, topcoat, final inspection, carbon finish)Surface | – | – | – | – | – |
| Quality assurance with 100% inspection of all componentsTesting | – | – | – | – | – |
| Optical 3D measuring system / 3D scanner (contactless geometry inspection, CAD comparison)Testing | – | – | – | – | – |
| Ultrasonic measurement/testing (material defects, internal structures, non-destructive)Testing | – | – | – | – | Fibre-composite components |
2 Anlagen & Maschinen
| Machine | Manufacturer / model | Quantity | Working area | Year built | Site |
|---|---|---|---|---|---|
| 5-axis milling machine | – | 2 | – | – | Heroldstatt |
| CNC-controlled finishing centre | – | – | – | – | Heroldstatt |
Additional services
Quality
Every component undergoes a 100% inspection before delivery. The inspection includes contactless optical 3D measurement with CAD comparison as well as non-destructive ultrasonic testing to check for material defects and layer quality.
| Evidence | Heroldstatt |
|---|---|
| ISO 9001:2015 | |
| EN 9100:2018 |
