Metalworking contract manufacturer for machining, sheet metal working and welding as well as mould making for roof tiles
Josef Maier Maschinen- und Dachziegelformenbau GmbH
StraubingNew on Amplifa
About us
Josef Maier Maschinen- und Dachziegelformenbau GmbH is a metalworking company in Straubing, founded in 1968. The company manufactures supply parts for mechanical engineering and the automotive industry, including for Sennebogen and International Automotive Components, as well as test components for Senton (TÜV Süd). A key focus is mould making for roof tiles, carried out for various brickworks. Production includes milling, turning, drilling, punching, sawing, bending and welding; small series and individual parts are manufactured to sample and drawing. In addition, the company carries out servicing and repairs of all kinds.
- Site
- Straubing
- Processes
- Milling (NC milling machine), Milling (conventional), Turning (conventional), Drilling (radial and pillar drilling machines), Punching (sheet metal and profiles, square and round), Bending (CNC press brake), Sheet metal cutting (sheet shear), Sawing (CNC automatic saw)
- Materials
- Metals, Sheet up to 8 mm
- Founded
- 1968
- Industries
- Mechanical engineering, Automotive suppliers, Brickworks/Building materials industry, Testing technology
- 01
Sawing and sheet metal cutting
- 02
Milling
- 03
Turning
- 04
Drilling
- 05
Punching and bending
- 06
Welding
- 07
Servicing and repair
Materials & Processes
Metals
Machining of metals in cutting, sheet metal working and welding.
Sheet up to 8 mm
Sheet metal cutting up to 8 mm thickness and 2000 mm length on the sheet shear.
Locations
Straubing
DEHeadquarters / Production
- Lot size
- Individual parts to small series
- Materials
- Metals, sheet metal
- CNC press brake (90 t, 2500 mm bending length)
- NC milling machine Reckermann (X 1000 / Y 350 / Z 350 mm)
- Conventional milling machine Reckermann (X 1200 / Y 400 / Z 350 mm)
- 5 conventional lathes (Ø 0–600 mm, turning length 0–2000 mm)
- CNC automatic saw up to Ø 350 mm
- Forte band saw up to Ø 400 mm
- Baikal sheet shear up to 8 mm / 2000 mm
- 2 Donau high-speed radial drilling machines (0–45 mm)
- 2 Fronius 320A welding systems (pulse units, rotary tables)
- Messer-Griesheim 300A TIG welding system
- Geka hydraulic punch
- Atlas grooving machine
- Epple mitre band saw
- 2 Alzmetall pillar drilling machines (0–45 mm)
Inside the production
Industries
Processes & technical limits
| Processes | Tolerance | Max. part | Weight | Lot size | Materials |
|---|---|---|---|---|---|
| Milling (NC milling machine)Machining | – | 1000 mm (X-axis) × 350 mm (Y) × 350 mm (Z) | – | Small series | Metal |
| Milling (conventional)Machining | – | 1200 mm (X-axis) × 400 mm (Y) × 350 mm (Z) | – | Small series | Metal |
| Turning (conventional)Machining | – | 2000 mm (turning length) × 600 mm (turning diameter) | – | Small series | Metal |
| Drilling (radial and pillar drilling machines)Machining | – | – | – | – | Metal |
| Punching (sheet metal and profiles, square and round)Forming | – | – | – | – | Sheet metal, Profiles |
| Bending (CNC press brake)Forming | – | 2500 mm (bending length) | – | – | Sheet metal |
| Sheet metal cutting (sheet shear)Machining | – | 2000 mm | – | – | Sheet metal up to 8 mm thickness |
| Sawing (CNC automatic saw)Machining | – | – | – | – | Metal up to 350 mm diameter |
| Band saws (conventional, mitre band saw)Machining | – | – | – | – | Metal up to 400 mm diameter |
| Welding (MAG, 2 welding systems 320A, pulse units and rotary tables)Joining | – | – | – | – | Metal |
| TIG weldingJoining | – | – | – | – | Metal |
| Manufacture of individual parts and small series to sample and drawingProduction | – | – | – | Individual parts – Small series | Metal |
| Servicing and repairs of all kindsAssembly | – | – | – | – | – |
14 Anlagen & Maschinen
| Machine | Manufacturer / model | Quantity | Working area | Year built | Site |
|---|---|---|---|---|---|
| CNC press brake | – | 1 | 90 tonnes, 2500 mm bending length | – | Straubing |
| NC milling machine | Reckermann | 1 | X=1000 mm, Y=350 mm, Z=350 mm | – | Straubing |
| Conventional milling machine | Reckermann | 1 | X=1200 mm, Y=400 mm, Z=350 mm | – | Straubing |
| Conventional lathe | – | 5 | Turning diameter 0–600 mm, turning length 0–2000 mm, centre height 270 mm | – | Straubing |
| CNC automatic saw | – | 1 | up to 350 mm diameter | – | Straubing |
| Conventional band saw | Forte | 1 | Diameter 400 mm | – | Straubing |
| Sheet shear | Baikal | 1 | up to 8 mm thickness, 2000 mm length | – | Straubing |
| High-speed radial drilling machine | Donau | 2 | 0–45 mm | – | Straubing |
| Welding system | Fronius 320A | 2 | – | – | Straubing |
| TIG welding system | Messer-Griesheim 300A | 1 | – | – | Straubing |
| Hydraulic punch | Geka | 1 | – | – | Straubing |
| Grooving machine | Atlas | 1 | – | – | Straubing |
| Mitre band saw | Epple | 1 | – | – | Straubing |
| Pillar drilling machine | Alzmetall | 2 | 0–45 mm | – | Straubing |
Additional services
Reference customers
History
- 1968
Founding of the company Josef Maier by the father of the current owner Harald Maier.
- 1985
Expansion of the production area through the addition of a workshop hall.
- 1986
Harald Maier passes the master craftsman examination in mechanical engineering.
- 1999
Harald Maier takes over the company Josef Maier; founding of Josef Maier Maschinen- und Dachziegelformenbau GmbH; addition of a material warehouse.
- 2005
Addition of a welding shop.
