Manufacturing of swaged and forged parts by chipless rotary swaging and radial forging in Gau-Algesheim
Metalltechnik Menges GmbH
Gau-AlgesheimNew on Amplifa
About Metalltechnik Menges GmbH
Metalltechnik Menges GmbH has been active in the field of chipless forming for over 30 years and specialises in the rotary swaging (hammer process) and radial forging processes. In rotary swaging, tubes, bars and other rotationally symmetrical workpieces are precisely formed – in feed and infeed rotary swaging as well as in combined form. As an incremental forming process in the cold, semi-hot and hot ranges, radial forging enables the production of complex workpiece contours, including combined axial-radial forming. The company manufactures production parts from prototypes and pre-series and small series through to large series, as well as single-piece gap filling in the event of production failures. In addition, Metalltechnik Menges offers process development, production part design and surface finishing – including the production of smooth inner surfaces of tubes. The machine fleet is versatile and coordinated with one another; all production takes place at one site in Gau-Algesheim. Customers are found in industries such as drive technology, the automotive industry, e-mobility, mechanical and plant engineering, medical and dental technology, aerospace engineering, metrology and control technology, the furniture industry and sporting firearms technology.
- Site
- Gau-Algesheim
- Processes
- Rotary swaging (feed rotary swaging and infeed rotary swaging), Radial forging (incremental forming process in the cold, semi-hot and hot ranges), Combined axial-radial forming, Surface finishing (e.g. inner surfaces of tubes with low roughness), Production part development/conception (prototype production, pre-series, process development), Rotary swaging (feed and infeed rotary swaging), Radial forging (cold, semi-hot and hot forming), Production of prototypes, pre-series, small series and large series
- Materials
- Rotary swaging (feed and infeed rotary swaging), Radial forging, Combined axial-radial forming, Surface finishing
- Certificates
- DIN EN ISO 9001:2015, ISO 9001
- Industries
- Drive technology, Mechanical and plant engineering, Dental technology, Automotive industry, Medical technology, Furniture industry
- 01
Production part design and process development
- 02
Rotary swaging (feed and infeed rotary swaging)
- 03
Radial forging (cold, semi-hot and hot forming)
- 04
Surface finishing
- 05
Prototype, pre-series, small and large series production
Materials and Processes
Rotary swaging (feed and infeed rotary swaging)
Precise chipless forming process for tubes, bars and other rotationally symmetrical workpieces with short machining times, tight tolerances, uninterrupted grain flow and material savings.
Radial forging
Incremental forming process in the cold, semi-hot and hot ranges for complex workpiece contours without temperature or material restrictions.
Combined axial-radial forming
Process combination of radial forging for particularly versatile contour designs.
Surface finishing
Production of inner surfaces of tubes with low roughness (Ra < 0.2) and a high bearing ratio (> 85%).
Sites
Gau-Algesheim
DEProduction and administration
- Lot size
- Single piece, prototype, pre-series, small series, large series
- Rotary swaging machines (feed and infeed rotary swaging)
- Radial forging machines
Industries
Processes & technical limits
| Processes | Tolerance | Max. part | Weight | Lot size | Materials |
|---|---|---|---|---|---|
| Rotary swaging (feed rotary swaging and infeed rotary swaging)Forming | tight tolerances (not specified) · Ra < 0.2 (inner surfaces of tubes) | – | – | Single piece – Large series | Tubes, Bars and other rotationally symmetrical workpieces |
| Radial forging (incremental forming process in the cold, semi-hot and hot ranges)Forming | tightest tolerances (not specified) | – | – | Single piece/prototype – Large series | no temperature or material restrictions |
| Combined axial-radial formingForming | – | – | – | – | – |
| Surface finishing (e.g. inner surfaces of tubes with low roughness)Surface | Ra < 0.2, bearing ratio > 85% | – | – | – | Tubes |
| Production part development/conception (prototype production, pre-series, process development)Engineering | – | – | – | Single piece – Large series | – |
Additional services
Quality
Metalltechnik Menges GmbH has a certified quality management system in accordance with DIN EN ISO 9001:2015 for the machining of metal parts, audited by ZDH-ZERT GmbH (certificate Q1 0197053, valid until 09.05.2028).
| Evidence | Gau-Algesheim |
|---|---|
| ISO 9001 |
History
Foundation of the company by Karlheinz Menges, Ing. (grad.)
Over 30 years of activity in the field of chipless forming (rotary swaging and radial forging)
Thomas Menges, Dipl.-Ing. (FH), takes over ownership and management
