Development and manufacturing of Class-3 microelectronics, implantable lithium primary batteries, LTCC substrates, hermetic feedthroughs and Nitinol components for active medical implants.
Micro Systems Technologies Management GmbH
Berlin · Pirna · Berg (Upper Franconia) · Rostock · Lake Oswego, OR (USA) · Singapore · Netanya (IL)New on Amplifa
MST Group Competencies
Micro Systems Technologies Management GmbH (MST), headquartered in Berlin, is a group of technology companies that has been developing and manufacturing Class-3 medical electronics and complete solutions for active implantable medical devices (AIMD) for over 40 years. The portfolio includes miniaturized microelectronics assemblies and semiconductor packaging (System in Package), LTCC ceramic substrates for RF and microwave applications, hermetic metal-glass feedthroughs, and Nitinol components with processes such as precision laser cutting (cutting widths from 15 µm, tubes up to Ø 30 mm), micro blasting, electropolishing, electroplated gold coating, shape setting/annealing and chemical treatment. LITRONIK Batterietechnologie GmbH in Pirna has been manufacturing primary batteries based on lithium-iodine, lithium-manganese dioxide and lithium-carbon monofluoride for pacemakers, defibrillators and neurostimulators since 1990 – with laser-welded housings made of titanium or 1.4306, dry room production, a high degree of automation and MES-integrated processes that are 100% traceable. Services include design-for-manufacturing, system integration, validation and qualification according to Class-3 requirements as well as FDA submission support. The group supplies manufacturers of active implants in Europe, the USA and the Asia-Pacific region.
- Site
- Berlin
- Processes
- Laser cutting (tubes up to Ø 30 mm, flat laser cutting, cutting widths from 15 µm, minimal HAZ), Micro blasting (deburring, cleaning, edge rounding, surface structuring), Electro polishing (electropolishing, corrosion resistance, biocompatibility), Galvanic coating / electroplated gold plating (X-ray visibility, electrical conductivity,, Shape setting and annealing of Nitinol (forming + heat treatment, in-house forming tools), Chemical treatment (chemical cleaning, pickling, surface activation), Simulation and testing (FEA, fatigue-to-fracture, tensile testing, surface characterization,, Laser and plasma welding (battery manufacturing, laser-welded titanium housings)
- Materials
- Nitinol, Gold (electroplated coating), 1.4306 (X2 CrNi 19.11) battery housing, Titanium (laser-welded battery housings), Lithium-manganese dioxide (Li-MnO2), Lithium-iodine (Li-I), Lithium-carbon monofluoride (Li-CFx), LTCC ceramic
- Certificates
- ISO 13485:2016, ISO 9001:2015, ISO 50001:2018
- Founded
- LITRONIK
- Employees
- MST Group: more
- Industries
- Medical technology (active implants: pacemakers, defibrillators,, Class III medical devices
- 01
Design-for-Manufacturing and Engineering
- 02
Cathode synthesis and powder processing
- 03
Laser cutting / micro blasting (Nitinol)
- 04
Shape setting / heat treatment
- 05
Electropolishing / electroplated gold coating
- 06
Laser and plasma welding (hermetic housings)
- 07
Microelectronics Assembly / Packaging and System Integration
- 08
Validation, qualification and testing
- 09
FDA submission support and series production
Materials and Processes
Stainless steel 1.4306 (X2 CrNi 19.11)
Hermetically welded housing material for the implantable battery cells.
Titanium
Laser-welded battery housings and metal-glass feedthroughs guarantee hermeticity.
Nitinol
Material for medical components in the manufacturing of Micro Nitinol Technology GmbH in Rostock.
Gold
Electroplated coating for X-ray visibility, conductivity and corrosion protection.
Lithium-Iodine, Lithium-Manganese Dioxide, Lithium-Carbon Monofluoride
Electrochemical systems for high-energy, medium-rate and high-power primary batteries.
LTCC ceramic
Ceramic substrates for RF and microwave applications in active implants.
Locations
Berlin
DEHeadquarters and Sales & Marketing Office Europe
Pirna
DELITRONIK Batterietechnologie GmbH – battery production
- Materials
- Lithium-iodine, Li-MnO2, Li-CFx, titanium, 1.4306, plastic
- Laser welding systems
- Plasma welding systems
- 4 dry rooms
- MES-integrated production systems
- Testing systems for electrical characterization and reliability testing
Berg (Upper Franconia)
DEMicro Systems Engineering GmbH – ceramics and packaging
- Materials
- LTCC ceramic
Rostock
DEMicro Nitinol Technology GmbH – Nitinol manufacturing
- Part weight / size
- Tubes up to Ø 30 mm
- Lot size
- Prototypes and low volumes
- Materials
- Nitinol
- Precision laser cutting systems (cutting widths from 15 µm)
- Micro blasting systems
Components and Product Groups
Inside the production
Industries
Processes & technical limits
| Processes | Tolerance | Max. part | Weight | Lot size | Materials |
|---|---|---|---|---|---|
| Laser cutting (tubes up to Ø 30 mm, flat laser cutting, cutting widths from 15 µm, minimal HAZ)Machining | minimal surface roughness (exact | – | – | – | Nitinol, various other materials (not specified) |
| Micro blasting (deburring, cleaning, edge rounding, surface structuring)Surface | – | – | – | – | Nitinol |
| Electro polishing (electropolishing, corrosion resistance, biocompatibility)Surface | – | – | – | – | Nitinol |
| Galvanic coating / electroplated gold plating (X-ray visibility, electrical conductivity,Surface | – | – | – | – | Nitinol, Gold |
| Shape setting and annealing of Nitinol (forming + heat treatment, in-house forming tools)Heat treatment | – | – | – | – | Nitinol |
| Chemical treatment (chemical cleaning, pickling, surface activation)Surface | – | – | – | – | Nitinol |
| Simulation and testing (FEA, fatigue-to-fracture, tensile testing, surface characterization,Testing | – | – | – | – | Nitinol |
| Laser and plasma welding (battery manufacturing, laser-welded titanium housings)Joining | – | – | – | – | Titanium, 1.4306, Plastic |
| Manufacture of primary battery cells and battery packs (Li-I, Li-MnO2, Li-CFx;Assembly | – | – | – | – | Lithium, Lithium-iodine, Lithium-manganese dioxide, Lithium-carbon monofluoride, Titanium (housing), 1.4306 (housing) |
| Chemical synthesis of cathode material and powder processing (milling, separation, drying,Plastics | – | – | – | – | Lithium-manganese dioxide, Lithium-iodine, Lithium-carbon monofluoride |
| Metal and plastics engineering (battery housings/components)Joining | – | – | – | – | Metals (unspecified), Plastics |
| Chemical and physical analytics (ICP-OES, IR spectroscopy, gas chromatography,Testing | – | – | – | – | – |
| Microelectronics assembly / Class 3 assembly for medical implantsAssembly | – | – | – | – | – |
| Semiconductor packaging / System in PackageAssembly | – | – | – | – | – |
| LTCC substrates (low-temperature co-fired ceramic) for RF and microwave applicationsJoining | – | – | – | – | Ceramic (LTCC) |
| Hermetic feedthroughs (hermetic, biocompatible feedthrough components,Joining | – | – | – | – | Glass, Metal (titanium) |
| Low-volume production and rapid prototyping of Nitinol componentsForming | – | – | – | Low volume | Nitinol |
5 Anlagen & Maschinen
| Machine | Manufacturer / model | Quantity | Working area | Year built | Site |
|---|---|---|---|---|---|
| Laser cutting machines (precision laser cutting) | – | – | Tubes up to Ø 30 mm; cutting widths from 15 µm | – | Rostock |
| Micro blasting machines | – | – | – | – | Rostock |
| Laser welding systems | – | – | – | – | Pirna |
| Plasma welding systems | – | – | – | – | Pirna |
| Dry rooms (production equipment under ultra-dry conditions) | – | 4 | 5600 m2 production floor space | – | Pirna |
Additional services
Reference customers
Quality and Certification
The quality management systems are geared toward life-sustaining implants: all processes and materials are 100% traceable, and battery production is MES-integrated under dry room conditions. Testing includes ICP-OES, IR spectroscopy, gas chromatography, Karl Fischer analysis, BET surface area determination, microcalorimetry as well as corrosion testing in accordance with ASTM F2129 and nickel ion release in accordance with ASTM F3306.
| Evidence | Pirna | Berg (Upper Franconia) | Lake Oswego (USA) |
|---|---|---|---|
| ISO 9001:2015 | |||
| ISO 13485:2016 | |||
| ISO 50001:2018 |
History
- 1990
Founding of LITRONIK Batterietechnologie GmbH, Pirna
- 1999
LITRONIK first certified to ISO 9001
- 2017
LITRONIK initial certification to EN ISO 13485:2016
Over 3 million batteries delivered from the Pirna Copitz plant; MST has been a partner for Class-3 medical electronics for over 40 years
