This is MICROS Optics
MICROS Optics is an owner-managed manufacturer of precision optics based in Schmiedefeld (Saalfeld), Thuringia, since 2001. The company manufactures flat optics such as flat plates, filters, mirrors, prisms, wedge plates, light guides and beam splitters, spherical optics such as lenses, achromats and cylindrical optics, refined technical glasses as well as optical thin films ranging from anti-reflective coatings to mirror, filter and beam splitter coatings, and also conductive transparent coatings (ITO). The portfolio is complemented by mechanical glass processing with CNC cutting, waterjet cutting, sawing, CNC milling, grinding and polishing, thermal and chemical toughening of glasses, as well as assembly of optical assemblies and systems. Optical components are manufactured with edge lengths from 0.5 to over 3,000 mm. On request, contract coating is carried out on substrates supplied by the customer. Products made from materials such as optical glasses from SCHOTT and OHARA, fused silica, borosilicate glass, sapphire and glass ceramics serve photonics, laser technology, medical technology, aerospace, sensor technology as well as the semiconductor and microscopy sectors. Worldwide delivery is made exclusively from German production at the main site in Schmiedefeld; a sales office in Rennerod (Rhineland-Palatinate) serves the customers. The company is certified to DIN EN ISO 9001.
- Site
- Saalfeld (OT Schmiedefeld)
- Processes
- Flat optics (flat plates/flat-parallel plates), Cutting/separating (CNC glass cutting machines), Waterjet cutting, Sawing / cut-off grinding, CNC milling / CNC drilling, Grinding/polishing, Laser processing (micro-drilling, marking, labeling), Spherical optics (lenses, achromats, cylindrical optics)
- Materials
- Borofloat 33, B270, Float glass, D 263 T eco, Fused silica, Sapphire, Glass ceramics, Borosilicate glass
- Certificates
- DIN EN ISO 9001
- Founded
- 2001
- Industries
- Photonics, Optical industry, Laser technology, Medical technology, Aerospace, Biometrics and biotechnology
- 01
Conceptual design
- 02
Design and tool development
- 03
Machining (cutting, milling, grinding, polishing)
- 04
Thin-film technology / coating
- 05
Cleaning
- 06
Assembly of optical assemblies
- 07
Testing and measurement
- 08
Packaging and delivery
Materials and processes
Thin-film technology (optical coating)
Optical and optoelectronic functional coatings in the spectral range 300 nm to 12 µm, also as contract coating.
Double-sided flat processing
Manufacture of flat and flat-parallel optics with roughnesses down to 0.5 nm RMS.
Spherical optics
Lenses, achromats and cylindrical optics with form errors down to λ/10 PV.
Waterjet cutting
Cutting of glasses up to 120 mm thickness.
Laser processing
Micro-drilling, marking and labeling of glasses and glass ceramics.
Thermal toughening
Toughening of float, Borofloat, flat and colored glasses.
Chemical toughening
Chemical strengthening of glasses.
Optical glasses (SCHOTT, OHARA)
Base material for lenses, achromats and flat optics.
Borofloat 33 / B270 / float glass / D 263 T eco
Technical glasses for refinement as individual parts or large series.
Fused silica / borosilicate glass
For optical windows, mirrors and filters with high transmission.
Sapphire / glass ceramics / ZnS
Special materials for demanding flat plates and flat-parallel plates.
Sites
Saalfeld (Schmiedefeld district)
DEHeadquarters / production site
- Part weight / size
- Components from Ø 0.5 mm to over 3,000 mm edge length
- Lot size
- Individual parts to large series
- Materials
- Optical glasses, fused silica, borosilicate glass, sapphire, glass ceramics, ZnS
- CNC-controlled glass cutting machines
- Waterjet cutting system
- Sawing / cut-off grinding machines
- CNC milling machines
- Evaporation systems (coating)
- Coating system (2018)
- Fully automatic ultrasonic cleaning line
- Interferometer ZYGO GPI-XP 4"
- Interferometer LT-Ultra IFM 12"
- Interferometer FISBA µPhase 1000
- Goniometer TRIOPTICS PrismMaster
- White-light interferometer Polytec TopMap Micro.View
- Spectrophotometer Perkin Elmer LAMBDA 950/1050
- 3D coordinate measuring machine MITUTOYO
Components
Inside the production
Industries
Processes & technical limits
| Processes | Tolerance | Max. part | Weight | Lot size | Materials |
|---|---|---|---|---|---|
| Flat optics (flat plates/flat-parallel plates)Surface | down to 0.5 nm RMS | 3,000 mm | – | – | Optical glasses (SCHOTT, OHARA), Fused silica, Sapphire, Filter glasses, Glass ceramics, Ceramics, Borosilicate glasses, ZnS |
| Cutting/separating (CNC glass cutting machines)Machining | – | – | – | – | coated and uncoated glasses |
| Waterjet cuttingMachining | – | 120 mm thickness | – | – | Glasses |
| Sawing / cut-off grindingMachining | – | – | – | – | Glasses |
| CNC milling / CNC drillingMachining | – | – | – | – | Glasses |
| Grinding/polishingSurface | – | 3,000 mm × 1,600 mm (Ø or diagonal) | – | – | Glasses |
| Laser processing (micro-drilling, marking, labeling)Machining | – | – | – | – | Glasses and glass ceramics |
| Spherical optics (lenses, achromats, cylindrical optics)Surface | up to ± 5 µm · 0.5 nm RMS | Ø 380 mm | – | – | Optical glasses (SCHOTT, OHARA), Fused silica, Filter glasses, Glass ceramics, Borosilicate glass |
| Thin-film technology / optical coatingsSurface | – | – | – | – | Optical glasses, Float and borosilicate glasses, Fused silica, Glass ceramics |
| Thermal toughening of glassesHeat treatment | – | – | – | – | Float glass, Borofloat glass, Flat glass, Colored glass |
| Chemical toughening of glassesHeat treatment | – | – | – | – | Glass |
| Optical assemblies and systems (cementing, assembly)Assembly | – | – | – | – | Optical components |
| Testing/measuring (visual defect inspection, angle measurement, parallelism measurement,Inspection | – | – | – | – | – |
19 Anlagen & Maschinen
| Machine | Manufacturer / model | Quantity | Working area | Year built | Site |
|---|---|---|---|---|---|
| CNC-controlled glass cutting machines | – | – | – | – | Schmiedefeld |
| Waterjet cutting system | – | – | – | – | Schmiedefeld |
| Sawing / cut-off grinding machines | – | – | – | – | Schmiedefeld |
| CNC milling machines | – | – | – | – | Schmiedefeld |
| Evaporation systems (coating) | – | – | – | – | Schmiedefeld |
| Coating system | – | – | – | 2018 | Schmiedefeld |
| Ultrasonic cleaning line (fully automatic) | – | – | – | 2018 | Schmiedefeld |
| Interferometer ZYGO GPI-XP 4" | ZYGO GPI-XP 4" | – | Flat surfaces 4" | – | Schmiedefeld |
| Interferometer LT-Ultra IFM 12" | LT-Ultra IFM 12" | – | Flat surfaces 12" | – | Schmiedefeld |
| Interferometer LT-Ultra 4" | LT-Ultra 4" | – | Flat surfaces 4" | – | Schmiedefeld |
| Interferometer FISBA µPhase 1000 | FISBA µPhase 1000 | – | Radii | – | Schmiedefeld |
| Interferometer Möller-WEDEL VI-direct | Möller-WEDEL VI-direct | – | Radii | – | Schmiedefeld |
| Goniometer TRIOPTICS PrismMaster | TRIOPTICS PrismMaster | – | Angle measurement | – | Schmiedefeld |
| Goniometer ZEISS workshop 1 | ZEISS | – | Angle measurement | – | Schmiedefeld |
| Goniometer ZEISS workshop 2 | ZEISS | – | Angle measurement | – | Schmiedefeld |
| White-light interferometer Polytec TopMap Micro.View | Polytec TopMap Micro.View | – | Surface details, roughness, texture, microstructures | – | Schmiedefeld |
| Spectrophotometer Perkin Elmer LAMBDA 950 | Perkin Elmer LAMBDA 950 | – | – | – | Schmiedefeld |
| Spectrophotometer Perkin Elmer LAMBDA 1050 | Perkin Elmer LAMBDA 1050 | – | – | – | Schmiedefeld |
| 3D coordinate measuring machine MITUTOYO | MITUTOYO | – | Form and position measurement | – | Schmiedefeld |
Additional services
Quality
All components undergo documented inspection processes with visual defect inspection, angle, parallelism and roughness measurement, interferometer evaluation as well as spectral reflection/transmission measurement. On request, an inspection report with all required inspection characteristics is created; the company is certified to DIN EN ISO 9001.
| Evidence | Saalfeld (Schmiedefeld district) |
|---|---|
| DIN EN ISO 9001 |
History
- 2001
Founding of MICROS Präzisionsoptik GmbH & Co. KG in Schmiedefeld, Thuringia.
- 2002
Establishment of the sales office in Rennerod, Rhineland-Palatinate.
- 2003
Expansion of the production area to 600 m² for double-sided flat processing.
- 2004
Founding of MICROS Coatings GmbH & Co. KG in Hermsdorf, Thuringia.
- 2005
Expansion of the administrative facilities; expansion of the production area to 1,000 m².
- 2006
Commissioning of large-area production, optics up to 3,200 mm length.
- 2008
New construction of a production hall; expansion to 2,200 m²; commissioning of large-surface production, optics up to Ø 1,600 mm.
- 2009
Relocation of MICROS Coatings to Schmiedefeld, Thuringia.
- 2010
Expansion of double-sided flat processing by 40 %.
- 2011
10th company anniversary.
- 2012
Certification to DIN EN ISO 9001 by TÜV Hessen.
- 2013
New construction of the sales office.
- 2014
Renaming to MICROS Optics GmbH & Co. KG; expansion of the production area to 2,700 m².
- 2017
New construction of a production hall for the thin-film technology department.
- 2018
Move into the new production hall and commissioning of the systems; purchase of a coating system and a fully automatic ultrasonic cleaning line; purchase of the neighboring property (+1,200 m²).
- 2019
Modernization of part of a building for mechanical pre-production.
- 2020
Enlargement and modernization of the facilities for final inspection.
- 2021
20th anniversary of the company.
- 2024
Construction of a clean room for double-sided flat processing.
