About MIYAWAKI
MIYAWAKI Inc. is a Japanese manufacturer of steam equipment headquartered in Osaka. Founded in 1933, the company produces steam traps (including bucket float, ball float, bimetal temperature control, diaphragm capsule and thermodynamic valve disc types), pressure reducers, condensate pumps, hot water equipment, air vents, separators and accessories for steam and condensate systems. In addition, diagnostic and management systems for steam traps (STC-011, Dr. Trap PM301/PM15/PM500) and testing equipment are developed and manufactured. Production takes place at the headquarters and plant in Osaka; housing materials include stainless steel A182 F304 as well as forged steels such as F91, WC9, A105 and A182 F11. In addition to standard products, MIYAWAKI offers application-specific production with adaptations of face-to-face length, material, operating temperature, operating pressure and flow rate — up to 431 bar and 620 °C. Since the early 1990s, the company has offered a steam trap survey service, which, according to company statements, avoids more than 10,000 tonnes of CO2 emissions annually. Through its subsidiary MIYAWAKI GmbH in Frankfurt (Oder), the company serves the German-speaking and European market.
- Site
- Frankfurt (Oder)
- Processes
- Manufacture of steam equipment (steam traps, pressure reducers, hot water equipment,, Steam trap survey service (inspection of traps, bypass valves,, Production of testing/diagnostic equipment (steam trap diagnostic device STC-011, portable, Production of individual bore gauges for flange bolt inspection in the in-house production, Application-specific production (adaptation of face-to-face length, material, operating/maximum, Manufacture of machinist tools (original business field), Steam trap survey service, Steam trap diagnostics and management system (Dr. Trap)
- Materials
- Stainless steel A182 F304, Forged steel F91, WC9, A105, A182 F11, Bimetal (temperature-controlled trap), Bimetal
- Certificates
- ISO 9001, SBT for SMEs
- Founded
- 1933
- Employees
- 140
- Industries
- Food and beverage industry, Hotels and public facilities, Manufacturing industry, Laundry/dry cleaning, Plant engineering (steam systems), Power plant technology
- 01
Development and design
- 02
Production at the Osaka headquarters and plant
- 03
Quality inspection (including penetrant testing)
- 04
Sales via own branches and subsidiaries
- 05
Steam trap survey service and maintenance consulting
Materials and Processes
Stainless steel A182 F304
Housing material of the TB temperature-controlled trap series, e.g. for steam tracing lines and condensate return.
Forged steel F91
Housing material of application-specific steam traps for extreme temperature and pressure ranges up to 431 bar and 620 °C.
WC9
Housing material for high temperature and pressure ranges, among other things as a standard material before the material change to F91.
A105
Housing material of steam traps for nuclear power plants, alternatively A182 F11.
A182 F11
Housing material of steam traps for power plant applications.
Bimetal
Functional element of the temperature-controlled traps manufactured since 1973 for energy-saving condensate discharge.
Locations
Osaka
JPHeadquarters and plant
- Materials
- Stainless steel A182 F304, forged steels F91, WC9, A105, A182 F11
- Production department with in-house gauge manufacturing
- Testing and diagnostic equipment production
Frankfurt (Oder)
DESubsidiary MIYAWAKI GmbH, sales and service for Europe
Wuxi
CNSubsidiary Miyawaki West Co., Ltd.
Seoul
KRSubsidiary MIYAWAKI Korea INC.
Yekaterinburg
RUAffiliated company OOO MIYAWAKI
Products and Components
Inside the production
Industries
Processes & technical limits
| Processes | Tolerance | Max. part | Weight | Lot size | Materials |
|---|---|---|---|---|---|
| Manufacture of steam equipment (steam traps, pressure reducers, hot water equipment,Assembly | – | – | – | – | Stainless steel A182 F304, Forged steel F91, WC9, A105, A182 F11 |
| Steam trap survey service (inspection of traps, bypass valves,Testing | – | – | – | – | – |
| Production of testing/diagnostic equipment (steam trap diagnostic device STC-011, portableTesting | – | – | – | – | – |
| Production of individual bore gauges for flange bolt inspection in the in-house productionTesting | – | – | – | – | – |
| Application-specific production (adaptation of face-to-face length, material, operating/maximumEngineering | – | – | – | – | Stainless steel, WC9, F91 |
| Manufacture of machinist tools (original business field)Assembly | – | – | – | – | – |
Additional services
Quality
The headquarters plant is certified to ISO 9001 (previously ISO 9002 from 1993). Quality assurance includes, among other things, penetrant testing, calibration of measuring instruments, customer acceptances and in-house production of inspection gauges, complemented by a survey service with company-certified technicians.
| Evidence | Osaka |
|---|---|
| ISO 9001 |
Company History
- 1933
Sentaro Miyawaki founds Miyawaki Shoten in Osaka for the manufacture of machinist tools
- 1949
Double steam trap Model F with patented pressure differential technology released
- 1950
Steam trap Model R released
- 1953
MIYAWAKI Steam Trap Manufacturing Co., Ltd. founded; business operations started in December 1953
- 1962
Bimetal steam trap Model B released based on technology from Dr. Domnick and K. Schroeder (West Germany)
- 1969
Relocation of headquarters/plant to Tagawakita, Yodogawa-ku, Osaka (current location)
- 1973
Energy-saving temperature-controlled trap TB2 released
- 1982
Steam trap technology transfer to BVMI (UK); diagnostic device STC-011 released
- 1984
Sales partnership with ITT (USA), expansion into the US market
- 1986
CI introduced, renamed Miyawaki Inc.
- 1991
Subsidiary Miyawaki GmbH founded in Berlin, Germany
- 1993
ISO 9002 certification received (headquarters/plant)
- 2001
ISO 9001 certification received; Dr. Trap PM301 steam trap management system released
- 2009
Kensuke Miyawaki appointed President
- 2013
Branch opened in Wuxi, Jiangsu Province, China
- Frühe 1990er
Introduction of the regular steam trap maintenance service; today avoidance of more than 10,000 t of CO2 emissions per year
- 2026
SBTs for SMEs certification for greenhouse gas emission reduction targets received
