Manufactures jigs and fixtures, special machinery and production systems with development, mechanical manufacturing, automation and service from a single source.
MSA-Vorrichtungsbau GmbH
57612 EichelhardtNew on Amplifa
About MSA-Vorrichtungsbau
MSA-Vorrichtungsbau GmbH is an owner-managed medium-sized company headquartered in Eichelhardt in the Westerwald region. Its portfolio of services includes jig and fixture construction, special machinery construction, production system construction, prototype construction as well as small-batch and series production, also using 3D printing. In addition, MSA offers automation solutions, PLC programming as well as process and production data acquisition. Mechanical manufacturing is performed on a networked machine fleet to Industry 4.0 standards, including a variety of grinding and EDM machines for minimal tolerances, including cylindrical grinding of rotationally symmetrical workpieces. Beyond manufacturing, the company provides project management, commissioning as well as maintenance and repair. Customers come primarily from mechanical and plant engineering; deliveries are made worldwide.
- Site
- Eichelhardt
- Processes
- Jig and fixture construction (assembly fixtures), Special machinery construction, Production system construction, Prototype construction, Small-batch/series production (also with 3D printing), Grinding, Cylindrical grinding of rotationally symmetrical workpieces, EDM
- Materials
- Highest-quality materials (unspecified), Grinding, EDM, 3D Printing, PLC Programming, Process/Production Data Acquisition
- Certificates
- ISO 9001
- Industries
- Mechanical and plant engineering, Industry 4.0 / Automation
- 01
Development & Design
- 02
Mechanical Manufacturing (Grinding, EDM)
- 03
Assembly/Commissioning
- 04
Automation & PLC Programming
- 05
Process and Production Data Acquisition
- 06
Maintenance and Service
Materials & Processes
Grinding
Precision manufacturing process for maintaining minimal tolerances, including cylindrical grinding of rotationally symmetrical workpieces.
EDM
Electrical discharge machining process for precise contours in jig/fixture and special machinery manufacturing.
3D Printing
Additive manufacturing for prototypes and small batches with complex component properties.
PLC Programming
Design, setup and maintenance of programmable logic controllers as the centrepiece of automation systems.
Process/Production Data Acquisition
Digital acquisition, processing and long-term archiving of process and production data.
Locations
Eichelhardt
DEHeadquarters / Manufacturing
- Materials
- Metallic materials (unspecified)
- Grinding machines
- EDM machines
- Networked machine fleet (Industry 4.0)
Components
Inside the production
Industries
Processes & technical limits
| Processes | Tolerance | Max. part | Weight | Lot size | Materials |
|---|---|---|---|---|---|
| Jig and fixture construction (assembly fixtures)Assembly | – | – | – | – | – |
| Special machinery constructionAssembly | – | – | – | – | – |
| Production system constructionAssembly | – | – | – | – | – |
| Prototype constructionEngineering | – | – | – | – | – |
| Small-batch/series production (also with 3D printing)Machining | – | – | – | Small batches | – |
| GrindingMachining | minimal tolerances | – | – | – | – |
| Cylindrical grinding of rotationally symmetrical workpiecesMachining | – | – | – | – | – |
| EDMMachining | minimal tolerances | – | – | – | – |
| Mechanical manufacturingMachining | – | – | – | – | – |
| 3D printing (additive manufacturing for series production)Additive | – | – | – | – | – |
| Development & designEngineering | – | – | – | – | – |
| PLC programmingEngineering | – | – | – | – | – |
| CommissioningAssembly | – | – | – | – | – |
| Maintenance, repair and serviceAssembly | – | – | – | – | – |
| AutomationAssembly | – | – | – | – | – |
| Process data acquisitionTesting | – | – | – | – | – |
| Production data acquisitionTesting | – | – | – | – | – |
| Manufacturing-accompanying quality assuranceTesting | – | – | – | – | – |
3 Anlagen & Maschinen
| Machine | Manufacturer / model | Quantity | Working area | Year built | Site |
|---|---|---|---|---|---|
| Grinding machines | – | – | – | – | Eichelhardt |
| EDM machines | – | – | – | – | Eichelhardt |
| Machine fleet with Industry 4.0 networking | – | – | – | – | Eichelhardt |
Additional services
Quality
The high quality of services is ensured by ISO 9001 certification. In addition, MSA relies on manufacturing-accompanying quality assurance and the acquisition of process and production data.
| Evidence | Eichelhardt |
|---|---|
| ISO 9001 |
History
- 1999
Introduction of modern manufacturing to Industry 4.0 standards.
