Plant engineering for surface technology as well as steel construction, sheet metal processing and welded constructions up to 15 t unit weight.
Norbert Sapp GmbH
Eslohe-BremkeNew on Amplifa
Design. Manufacture. Install.
Norbert Sapp GmbH is a medium-sized family business in its third generation, based in Eslohe-Bremke in the Sauerland region. For over 30 years, the company has designed, manufactured and installed surface technology systems, including pretreatment systems (index-dip, index-spray and conveyorized spray systems), dryers, painting and coating systems, and conveying systems with PLC controls. As a second pillar, the company produces welded and steel constructions of all kinds, general sheet metal processing, machine frames and housings, as well as tank and apparatus construction. On 3,000 m² of production space, products designed at four CAD workstations are manufactured with unit weights of up to 15 t on mostly CNC-controlled machines – from CNC punching and bending to plasma and oxy-fuel flame cutting to welding using all common processes in steel, stainless steel and aluminium. The company is a certified specialist operation under the German Federal Water Act (WHG) with a monitoring contract with TÜV-Nord, and supplies customers nationwide as well as in neighboring countries.
- Site
- Eslohe-Bremke
- Processes
- CNC punching, CNC bending, Cutting, CNC fine-beam plasma cutting, CNC oxy-fuel flame cutting, Round bending, Welded constructions (all common welding processes), Sheet metal processing / bent parts / bent profiles
- Materials
- Steel, Galvanized steel, Stainless steel, Aluminium
- Certificates
- Certified specialist operation under § 19L WHG, Minor qualification proof according to DIN 18800, Certified specialist operation under § 19L WHG (TÜV-Nord, monitoring contract), Process qualification for all common welding processes
- Industries
- Surface technology/Coating, Automotive suppliers, Mechanical engineering, Metal processing, Furniture/Metal goods industry, Construction
- 01
Order preparation and consulting
- 02
Design (4 CAD workstations)
- 03
Production (sheet metal processing, cutting, welding)
- 04
Surface finishing of components
- 05
Installation
- 06
Maintenance service and spare parts warehouse
Materials and Manufacturing Processes
Steel
Main material for welded constructions, steel construction and plant engineering.
Galvanized steel
Used for CNC-punched parts with corrosion-protective galvanization.
Stainless steel
For stainless steel processing, tank and apparatus construction.
Aluminium
Used in welded constructions, sheet metal processing and CNC-punched parts.
Site
Eslohe-Bremke
DEMain site: production, design and administration
- Part weight / size
- up to 15 t per piece
- Lot size
- Single-unit production to assemblies
- Materials
- Steel, galvanized steel, stainless steel, aluminium
- CNC punching machine (sheet size 1,500 x 10,000 mm, max. 8 mm)
- CNC punching machine 3000 x 1500 mm
- CNC press brake up to 4000 mm length
- CNC fine-beam plasma cutting system 6000 x 2000 x 15 mm
- CNC oxy-fuel flame cutting system 6000 x 2000 x 200 mm
- Round bending machine 3000 x 6 mm
- 4 CAD workstations
Components
Inside the production
Industries
Processes & technical limits
| Processes | Tolerance | Max. part | Weight | Lot size | Materials |
|---|---|---|---|---|---|
| CNC punchingForming | – | 10,000 mm × 1,500 mm | 200 kg | – | Steel, Galvanized steel, Stainless steel, Aluminium |
| CNC bendingForming | – | 4000 mm | 200 to | – | Steel, Stainless steel, Aluminium |
| CuttingMachining | – | 4000 mm × 12 mm thickness | – | – | Steel, Stainless steel, Aluminium |
| CNC fine-beam plasma cuttingMachining | – | 6000 mm × 2000 mm × 15 mm | – | – | Steel, Stainless steel, Aluminium |
| CNC oxy-fuel flame cuttingMachining | – | 6000 mm × 2000 mm × 200 mm | – | – | Steel |
| Round bendingForming | – | 3000 mm × 6 mm | – | – | Steel, Stainless steel, Aluminium |
| Welded constructions (all common welding processes)Joining | – | – | 15 t | Single-unit production | Steel, Stainless steel, Aluminium |
| Sheet metal processing / bent parts / bent profilesForming | – | – | – | – | Steel, Stainless steel, Aluminium |
| Machining (incl. assemblies)Machining | – | – | – | – | Steel, Stainless steel, Aluminium |
| Machine frames and housings / machine standsAssembly | – | – | – | – | Steel, Stainless steel, Aluminium |
| Stainless steel processingJoining | – | – | – | – | Stainless steel |
| Tank construction / apparatus constructionJoining | – | – | – | – | Steel, Stainless steel |
| Planning and construction of pretreatment systems (index-dip system, index-spray system,Surface | – | – | – | – | Steel, Stainless steel, Aluminium |
| Electro-dip painting (ATL/KTL) - plant engineeringSurface | – | – | – | – | Steel, Stainless steel, Aluminium |
| Powder coating - plant engineeringSurface | – | – | – | – | Steel, Stainless steel, Aluminium |
| Wet painting - plant engineeringSurface | – | – | – | – | Steel, Stainless steel, Aluminium |
| Dryer plant construction (chamber dryers, conveyor dryers, circulating air ovens, preheating ovens,Surface | – | – | – | – | Steel, Stainless steel, Aluminium |
| Conveying technology plant construction (overhead conveyors, circular conveyors, Power & FreeEngineering | – | 12 mtr (workpiece length overhead | several tonnes (powered overhead | – | Steel |
| Special systems and special constructionsEngineering | – | – | – | – | Steel, Stainless steel, Aluminium |
7 Anlagen & Maschinen
| Machine | Manufacturer / model | Quantity | Working area | Year built | Site |
|---|---|---|---|---|---|
| CNC punching machine | – | – | Sheet size 1,500 x 10,000 mm, material thickness max. 8 mm | – | Eslohe-Bremke |
| CNC press brake | – | – | up to 4000 mm length | – | Eslohe-Bremke |
| CNC fine-beam plasma cutting system | – | – | 6000 x 2000 x 15 mm | – | Eslohe-Bremke |
| CNC oxy-fuel flame cutting system | – | – | 6000 x 2000 x 200 mm | – | Eslohe-Bremke |
| CNC punching machine | – | – | 3000 x 1500 mm | – | Eslohe-Bremke |
| Round bending machine | – | – | 3000 x 6 mm | – | Eslohe-Bremke |
| CAD workstations | – | 4 | – | – | Eslohe-Bremke |
Additional services
Reference customers
Quality and Approvals
The company is approved for all common welding processes and, since 1992, has been a certified specialist operation under the German Federal Water Act (WHG, § 19L) with a monitoring contract with TÜV-Nord, qualified for the manufacture, installation and maintenance of systems and tanks for water-hazardous substances.
| Evidence | Eslohe-Bremke |
|---|---|
| Certified specialist operation under § 19L WHG (TÜV-Nord, monitoring contract) | |
| Minor qualification proof according to DIN 18800 | |
| Process qualification for all common welding processes |
Company History
In existence for 75 years; family business in its 3rd generation
- 1980
Construction of a new production hall and relocation to the present site in Eslohe-Bremke; plant engineering for surface technology ever since
- 1992
Certified specialist operation under the WHG with monitoring contract with TÜV-Nord
