About Opsytec Dr. Gröbel
Opsytec Dr. Gröbel GmbH develops and manufactures industrial UV metrology: UV sensors for UVA, UVB and UVC, radiometers and spectral radiometers for measuring irradiance and UV dose, UV LED systems and area emitters, UV irradiation chambers as well as custom integrating spheres with diameters from 25 mm to 2.5 m. Development, manufacturing, the calibration laboratory and the testing laboratory are located at the Ettlingen site near Karlsruhe; the in-house manufacturing depth extends to in-house metalworking, enabling one-off parts, small series and long-term OEM repeat deliveries with customer branding. In addition to standard products, custom system sensors, special housings, optical systems and special machines are produced. The company's own calibration laboratory is accredited by DAkkS in accordance with DIN EN ISO/IEC 17025 and calibrates UV sensors and radiometers in the spectral range 200 to 1000 nm traceable to PTB. Fields of application are UV curing, UV adhesive bonding, UV disinfection, pharmaceutical photostability, materials testing, photochemistry and 3D printing. The technological roots reach back to 1981.
- Site
- Ettlingen
- Processes
- Accredited calibration of UV sensors and radiometers for irradiance (200 nm to 1000, Calibration of reference radiometers in accordance with ASTM G130-12(2020), Calibration of radiometers with artificial sources based on ASTM E824-26 and G130-12(2020), Linearity testing using the source addition method in accordance with DIN 19294-3:2020-08, Testing of the calibration of spectral radiometers in accordance with ASTM G138-12(2020)e1, Testing of the photobiological safety of UV lamp products in accordance with IEC 62471-6:2022, Testing of the spectral irradiance of a lamp in accordance with CIE 250:2022, Factory calibration of DVGW sensors in accordance with DIN 19294-1 to -4
- Materials
- Barium sulfate (BaSO₄), PTFE, Gold, Aluminium (housing of PTFE spheres), Barium sulfate, Aluminium
- Certificates
- DIN EN ISO 9001:2015, ISO/IEC 17025 accreditation calibration laboratory, ISO/IEC 17025 accreditation testing laboratory, ISO 9001:2015 (TÜV SÜD, no. 12 100 42114 TMS), ISO/IEC 17025 – calibration laboratory (DAkkS D-K-20284-01-00), ISO/IEC 17025 – testing laboratory (DAkkS D-PL-20284-01-00)
- Founded
- 1981
- Industries
- UV curing (varnishes, coatings, printing inks), UV adhesive bonding and polymerisation, UV disinfection (drinking water, wastewater), Pharmaceutical photostability (ICH Q1B), Materials testing and UV ageing, Photochemistry and photobiology
- 01
Development and design
- 02
Manufacturing incl. metalworking
- 03
Assembly and firmware/software
- 04
Calibration in the DAkkS-accredited laboratory
- 05
Testing and factory calibration certificate
- 06
Recalibration and service
Materials and Processes
Barium sulfate
Coating material for integrating spheres with high diffuse-reflective properties.
PTFE
Diffuser and sphere material for integrating spheres with high reflectance.
Gold
Coating for infrared-optimized integrating spheres.
Aluminium
Housing material for PTFE spheres and device constructions.
Sites
Ettlingen
DEDevelopment, manufacturing, calibration laboratory and testing laboratory (headquarters)
- Part weight / size
- Integrating spheres 25 mm to 2.5 m diameter
- Lot size
- One-off parts, small series, OEM repeat deliveries
- Materials
- Barium sulfate, PTFE, gold, aluminium, plastic
- UV-VIS double monochromator (200–1000 nm)
- Spectral radiometer
- Luminance meter
- Calibration light sources
- UV irradiation chambers BS-02 to BS-05, BSL, BSH, BSM-03, BS-OX
Products and Components
Inside the production
Industries
Processes & technical limits
| Processes | Tolerance | Max. part | Weight | Lot size | Materials |
|---|---|---|---|---|---|
| Accredited calibration of UV sensors and radiometers for irradiance (200 nm to 1000Testing | Measurement uncertainty ≥ 2.8 % | – | – | 0.2 µW/cm² – > 10 W/cm² | UV sensors, Radiometers |
| Calibration of reference radiometers in accordance with ASTM G130-12(2020)Testing | – | – | – | – | – |
| Calibration of radiometers with artificial sources based on ASTM E824-26 and G130-12(2020)Testing | – | – | – | – | – |
| Linearity testing using the source addition method in accordance with DIN 19294-3:2020-08Testing | – | – | – | – | UV measuring devices |
| Testing of the calibration of spectral radiometers in accordance with ASTM G138-12(2020)e1Testing | – | – | – | – | – |
| Testing of the photobiological safety of UV lamp products in accordance with IEC 62471-6:2022Testing | – | – | – | – | – |
| Testing of the spectral irradiance of a lamp in accordance with CIE 250:2022Testing | – | – | – | – | – |
| Factory calibration of DVGW sensors in accordance with DIN 19294-1 to -4Testing | – | – | – | – | DVGW sensors, Dosimeters, UV integrators |
| Linearity tests of UV measuring devices up to approx. 5 W/cm²Testing | – | – | – | – | – |
| Spectroscopy (UV, VIS, IR)Testing | – | – | – | – | – |
| Absorption, reflectance and transmission measurements, measurement of optical densityTesting | – | – | – | – | – |
| Measurement and assessment according to OStrV, RL/2006/25 and DIN EN 14255 (on site)Testing | – | – | – | – | – |
| Risk assessments for workplace safety (artificial optical radiation, in particularTesting | – | – | – | – | – |
| Classification for CE according to DIN EN 12198 under the Machinery DirectiveTesting | – | – | – | – | – |
| Development and manufacture of custom measuring devices, sensors, optical systems andEngineering | – | – | – | One-off parts – Small series | – |
| Metalworking (own manufacturing depth in the OEM sector)Machining | – | – | – | – | Metal |
| Custom manufacture of integrating spheres with diameters from 25 mm to 2.5 mEngineering | – | – | – | – | Barium sulfate, PTFE, Gold, Aluminium |
5 Anlagen & Maschinen
| Machine | Manufacturer / model | Quantity | Working area | Year built | Site |
|---|---|---|---|---|---|
| UV-VIS double monochromator | – | – | Spectral range 200 nm to 1000 nm | – | Ettlingen |
| Spectral radiometer (laboratory equipment) | – | – | – | – | Ettlingen |
| Luminance meter | – | – | – | – | Ettlingen |
| Calibration light source | – | – | – | – | Ettlingen |
| UV irradiation chamber (BS-02 to BS-05, BSL series, BSH-02, BSH-03 CBD, BSM-03, BS-OX) | Opsytec | – | – | – | Ettlingen |
Additional services
Quality and Accreditations
Opsytec is certified to DIN EN ISO 9001:2015 and operates two DAkkS-accredited laboratories under ISO/IEC 17025: a calibration laboratory (D-K-20284-01-00) for UV sensors and radiometers and a testing laboratory (D-PL-20284-01-00) for spectral radiometers, lamps and LED systems. Calibrations are traceable to national standards; the measurement uncertainty is ≥ 2.8 % depending on the spectrum.
| Evidence | Ettlingen |
|---|---|
| ISO 9001:2015 (TÜV SÜD, no. 12 100 42114 TMS) | |
| ISO/IEC 17025 – calibration laboratory (DAkkS D-K-20284-01-00) | |
| ISO/IEC 17025 – testing laboratory (DAkkS D-PL-20284-01-00) |
History
- 1981
Technological roots: UV and light calibrations have been performed since 1981.
- 2003
Delivery of a 2500 mm integrating sphere to PTB Braunschweig.
- 2017
Start of DAkkS-accredited calibration of broadband radiometers for irradiance.
