Develops, manufactures and tests electronic assemblies and devices as an EMS provider in Middle Franconia.
Raum & Lang Elektronik GmbH
Eckental-Brand (DE)New on Amplifa
About Raum & Lang
Raum & Lang Elektronik GmbH is an electronics manufacturing services (EMS) provider based in Eckental-Brand in Middle Franconia. The company develops electronic assemblies, brings prototypes to production readiness and handles complete contract manufacturing: SMD placement and soldering using vapor phase soldering (leaded and lead-free, single- and double-sided), THD placement with wave soldering, automated selective soldering under nitrogen atmosphere, as well as cable assembly and complete device assembly through to functional testing. All development, manufacturing and testing takes place exclusively at its own premises in Eckental; these include fully automatic SMD lines with SIPLACE placement machines (component range 0201, fine pitch 0.3 mm, BGA, edge lengths up to 78x56 mm) as well as a test laboratory with 3D AOI and manual microscope inspection according to IPC-A-610. Production runs consistently in air-conditioned rooms within an ESD protection zone. In addition, Raum & Lang handles material scheduling and procurement, including printed circuit board procurement, and keeps standard components on call in its own warehouse. As one of the first contract manufacturers, the company offers selective soldering and can look back on more than 20 years of experience in this field.
- Site
- Eckental-Brand
- Processes
- Electronics development, Electronics testing (test laboratory, specific tests to customer specifications), Electronics scheduling / material scheduling and procurement, SMD placement and soldering (vapor phase soldering, double-sided, leaded/lead-free), THD placement and soldering (through-hole technology, wave soldering/selective soldering), Selective soldering (automated, under nitrogen atmosphere), Device manufacturing (complete assembly, cable assembly, functional testing), Electronics development (prototypes brought to production readiness)
- Materials
- Printed circuit boards, SMD placement and vapor phase soldering, THD / through-hole technology, Selective soldering
- Certificates
- ISO 9001:2015, ISO 9001
- Industries
- Electronics services/EMS (contract manufacturing of electronic assemblies), Electronics services/EMS (contract manufacturing of electronic assemblies)
- 01
Electronics development / prototypes brought to production readiness
- 02
Material scheduling and procurement
- 03
SMD placement and vapor phase soldering
- 04
THD placement and wave soldering
- 05
Selective soldering
- 06
Device manufacturing / cable assembly
- 07
Functional testing and inspection
- 08
Warehousing
Technologies & Processes
SMD placement and vapor phase soldering
Double-sided, dense placement of small printed circuit boards; vapor phase soldering (IBL) heats assemblies evenly without shadowing effects, leaded or lead-free.
THD / through-hole technology
Through-hole placement of radial and axial components for mechanically robust applications such as connectors, switches and electrolytic capacitors, joined by wave or selective soldering.
Selective soldering
Fully automated, pinpoint-accurate soldering of wired components under nitrogen atmosphere, also for solder joints with high heat requirements.
Printed circuit boards
Procurement of printed circuit boards, including from the Asian market, as part of material scheduling.
Manufacturing Facility
Eckental-Brand
DEDevelopment, manufacturing, test laboratory, administration
- Lot size
- Prototypes, small series (SMD/selective soldering), series production
- Materials
- SMD, THD, selective soldering, device manufacturing
- SIPLACE SMD placement machines (fully automatic SMD lines)
- IBL vapor phase soldering system
- Selective soldering system
- OptiCon AOI system with 3D camera
- Manual THD placement stations
Services & Assemblies
Inside the production
Industries
Processes & technical limits
| Processes | Tolerance | Max. part | Weight | Lot size | Materials |
|---|---|---|---|---|---|
| Electronics developmentEngineering | – | – | – | – | – |
| Electronics testing (test laboratory, specific tests to customer specifications)Testing | – | – | – | – | – |
| Electronics scheduling / material scheduling and procurementEngineering | – | – | – | – | – |
| SMD placement and soldering (vapor phase soldering, double-sided, leaded/lead-free)Joining | – | 78x56mm | – | Prototypes and small series | Printed circuit boards |
| THD placement and soldering (through-hole technology, wave soldering/selective soldering)Joining | – | – | – | – | radial and axial components |
| Selective soldering (automated, under nitrogen atmosphere)Joining | – | – | – | Prototypes and small series | wired components |
| Device manufacturing (complete assembly, cable assembly, functional testing)Assembly | – | – | – | – | – |
4 Anlagen & Maschinen
| Machine | Manufacturer / model | Quantity | Working area | Year built | Site |
|---|---|---|---|---|---|
| SMD placement machines (fully automatic SMD lines) | SIPLACE | – | Component range 0201, fine pitch 0.3mm, BGA, max. edge length 78x56mm | – | Eckental-Brand |
| Vapor phase soldering system | IBL | – | – | – | Eckental-Brand |
| AOI system (automated optical inspection, 3D camera) | OptiCon | – | – | – | Eckental-Brand |
| Selective soldering system | – | – | – | – | Eckental-Brand |
Additional services
Quality
Raum & Lang manufactures according to the IPC-A-610 standard with multi-stage quality inspection: automated optical inspection (AOI) with a 3D camera (OptiCon) supplemented by manual microscope inspection, plus functional testing to customer specifications in its own test laboratory. The quality management system is certified to ISO 9001:2015 (DEKRA); production takes place exclusively within the ESD protection zone in air-conditioned rooms.
| Evidence | Eckental-Brand |
|---|---|
| ISO 9001 |
History
As one of the first contract manufacturers, Raum & Lang offers selective soldering and can look back on more than 20 years of experience in this field.
