Development, design and manufacture of clamping and gripping devices for turning, milling and grinding operations.
RÖHM GmbH
Sontheim an der Brenz (main plant, 41,000 sqm production area) · Dillingen an der Donau (branch plant) · St. Georgen (mandrel production)New on Amplifa
Clamping technology specialist since 1909
RÖHM GmbH, headquartered in Sontheim an der Brenz, is a manufacturer of clamping and gripping devices founded in 1909, with production sites in Sontheim, Dillingen an der Donau and St. Georgen. The company develops, designs and manufactures drill chucks, lathe chucks, face plates, power chucks, vises, centers, face drivers, steady rests, mandrels, collet chucks, cylinders, grippers, swivel units and tool clamping systems to SK and HSK standards. More than half of the products are custom special clamping devices; as a system supplier for turning and milling, the standard range comprises more than 7,000 items. Production is predominantly from steel and cast steel; at the Dillingen site, on portal turning and milling machines, workpieces up to 4 m in diameter and 25 t in weight are machined. The products are used, among others, in the automotive industry, aerospace, rail technology, energy technology, medical technology and in the machining of the smallest micro-components. RÖHM employs around 900 staff and delivers worldwide to more than 50 countries.
- Site
- Sontheim an der Brenz
- Processes
- Development, design and manufacture of clamping and gripping devices (clamping technology), Custom special clamping devices (more than half of the products are tailored solutions), System solutions for clamping and gripping (turning system, milling system, drilling, round and, Manufacture of drill chucks (quick-action drill chucks, gear-rim drill chucks) with runout accuracy, Manufacture of centers (revolving/dead) with max. 0.005 runout deviation, Manufacture of face drivers (CoAE series) up to 350 kg workpiece weight, up to 8 kN, Manufacture of power chucks, lathe chucks, face plates, vises, steady rests, mandrels, Manufacture of tool clamping systems (SK, HSK), change interfaces RESK, clamping heads SPK for
- Materials
- Steel, Cast steel
- Certificates
- ISO 9001:2015, ISO 14001:2015, ISO 50001:2018
- Founded
- 1909
- Employees
- approx. 900
- Industries
- Automotive / vehicle industry, Aerospace, Rail and rail-bound technology, Defense industry, Mechanical engineering, Micro technology (watch and jewelry industry, medical technology)
- 01
Engineering and design (standard, custom and system solutions)
- 02
Machining production (turning, milling, grinding)
- 03
Assembly and final inspection
- 04
Clamping device check with test certificate
- 05
After-sales support: installation, maintenance, repair, spare parts
Materials and manufacturing processes
Steel
Main material for heavily stressed clamping and gripping devices with high robustness and precision.
Cast steel
Used, among other things, for lathe chuck bodies employed in series production.
Production sites
Sontheim an der Brenz
DEMain plant / headquarters
- Materials
- Steel, cast steel
Dillingen an der Donau
DEBranch plant: lathe chucks, machine vises, special clamping devices; more than 300 employees
- Part weight / size
- Workpieces up to 4 m diameter and 25 t
- Materials
- Steel, cast steel
- 2 portal turning and milling machines (production hall 1,650 sqm, machine net weight 108 t)
St. Georgen
DEProduction site for standard and special mandrels
- Materials
- Steel
Products for clamping and gripping
Inside the production
Industries
Processes & technical limits
| Processes | Tolerance | Max. part | Weight | Lot size | Materials |
|---|---|---|---|---|---|
| Development, design and manufacture of clamping and gripping devices (clamping technology)Engineering | – | – | – | – | Steel, Cast steel |
| Custom special clamping devices (more than half of the products are tailored solutions)Engineering | – | – | – | – | – |
| System solutions for clamping and gripping (turning system, milling system, drilling, round andEngineering | – | – | – | – | – |
| Manufacture of drill chucks (quick-action drill chucks, gear-rim drill chucks) with runout accuracyClamping technology manufacturing | Runout accuracy down to 0.05 mm | – | – | – | – |
| Manufacture of centers (revolving/dead) with max. 0.005 runout deviationClamping technology manufacturing | max. 0.005 runout deviation | – | – | – | – |
| Manufacture of face drivers (CoAE series) up to 350 kg workpiece weight, up to 8 kNClamping technology manufacturing | Runout accuracy 0.01 mm | – | 350 kg | – | – |
| Manufacture of power chucks, lathe chucks, face plates, vises, steady rests, mandrelsClamping technology manufacturing | – | – | – | – | – |
| Manufacture of tool clamping systems (SK, HSK), change interfaces RESK, clamping heads SPK forClamping technology manufacturing | – | – | – | – | – |
| Manufacture of special clamping devices and handling fixtures for cleanrooms up to cleanroom classClamping technology manufacturing | – | – | – | – | – |
| After-sales support: installation, commissioning, clamping device check with test certificate,Testing | – | – | – | – | – |
| Real-time clamping force measurement during machining (sensor-equipped clamping jaw iJaw) incl.Testing | – | – | – | – | – |
| Machining of workpieces up to 4 m diameter and 25 t weight on portal turning and milling machinesMachining | – | Diameter up to 4 m | 25 t | – | – |
| Manufacture of sleeve mandrels, sliding-jaw mandrels and hydraulic expansion mandrels (mechanical,Clamping technology manufacturing | – | – | – | – | – |
2 Anlagen & Maschinen
| Machine | Manufacturer / model | Quantity | Working area | Year built | Site |
|---|---|---|---|---|---|
| Portal turning and milling machine | – | 2 | Workpieces up to 4 m diameter and 25 t weight (1,650 sqm production hall, machine net weight 108 | – | Dillingen/Donau |
| 5-axis machining center KERN Micro (customer application, not part of RÖHM's equipment) | KERN KERN Micro | – | – | – | IWC Schaffhausen (customer) |
Additional services
Reference customers
Quality and certification
The RÖHM Group applies strict quality controls supported by state-of-the-art electronic measurement methods; the initial certification to DIN EN ISO 9001 took place in 1997, and since 2009 a matrix certification of all branches by TÜV Management Service has been in place. In addition, RÖHM offers the clamping device check with test certificate as well as the sensor-equipped clamping jaw iJaw for in-process clamping force measurement.
| Evidence | Sontheim an der Brenz | Dillingen an der Donau | St. Georgen |
|---|---|---|---|
| ISO 9001:2015 | |||
| ISO 14001:2015 | |||
| ISO 50001:2018 |
Company history
- 1909
Founded by Heinrich Röhm in Zella-Mehlis (Thuringia); first product: two-jaw drill chuck
- 1910
First patent for improved drill chucks; start of export business
- 1926
First German manufacturer of gear-rim drill chucks
- 1939/1940
40 m conveyor belt; first series production of precision tools
- 1945
Factory in Zella-Mehlis expropriated; at that time the company employed 1,400 people
- 1946
Re-establishment of the company in Sontheim/Brenz by Heinrich Röhm and sons
- 1953
Foundation of the Dillingen an der Donau branch plant
- 1959
Foundation of the England sales subsidiary
- 1960
Subsidiaries in Denmark, Brazil and Switzerland
- 1969
Subsidiary Italy
- 1978
Subsidiary USA
- 1979
Subsidiary France
- 1980
Foundation of the St. Georgen site (mandrels)
- 1984
Günter Röhm takes over management
- 1985
Subsidiary Spain
- 1997
Initial certification to DIN EN ISO 9001 (TÜV Management Service)
- 2007
Foundation of RÖHM Slovakia, RÖHM India and the joint venture RÖHM WEIDA Machinery China; new production hall in Dillingen with portal turning and milling machines (workpieces up to 4 m diameter)
- 2008
Transition of management from the Röhm family to an external management
- 2010
Sale of the weapons division (RG) to Umarex; focus on core competence in clamping technology
